LB-800 Slimline design pumps allow to fit into 8″ pipes. Powerful pump built with durable materials in an easy handling design. Top discharge provides maximum motor cooling efficiency allowing continuous duty operation at low levels and extended dry-run capability.
Technical Specifications
Motor Output (HP): 1Phase: SingleDischarge Bore (in.): 2Voltage/Amp: 115/9.6Cable Length (ft.): 50Dimension (Dia x H, in.): 7-9/16 x 13-7/16Continuous Running Water Level (in.): 2Pump Weight (lbs.): 35
Features
-Designed to fit an 8″ pipe.
-Up to 59’ shut off head.
-Dual Inside Mechanical Seal With SiC faces provides longer operational life.
-Oil Lifter provides lubrication of the seal faces. (Patented)
