Combination service entrance device (CSED), referred to as an all-in-one that includes the utility meter socket, main service disconnect and integral load center in a single enclosure. Ring type and overhead or underground feed, rated 200 A and surface mount. 1-phase, 3-wire. 10,000 short circuit rating. 20 space, 40 circuit. Meets EUSERC standards. Service disconnects are supplied factory installed. Supplied with 100% branch neutrals. Meets Federal Specification W-P-115c as Type 1, Class 2. Convertible to semiflush with SC200F flange kit (sold separately). Suitable only for use as service equipment. UL listed.
Product specification\n\n
\n
| Brand | Square D |
|---|---|
| UPC | 785901859093 |
| Model Number | SC2040M200C |
| Category | ELECTRICAL |
| Additional Category | Combination Load Centers |
| Length | 7.5 |
| Width | 15.75 |
| Height | 33.75 |
| Weight | 50.38 |
