Ultrasonic welding and integrated construction of the strap and body. Backwire clamps on the side terminals for installation of #12 and #14 wire. Thermoplastic rocker, top and back body are virtually unbreakable. Screws accept slotted, Phillips and Robertson head tools for installation in both the USA and Canada. Longer, wider strap provides 40% more contact area to wall board. Virtually eliminates floating installations. Built-in wire stripper for #12 and #14 wire. Stippled ground screw standard. 15 A, 120/277 VAC rating for fluorescent lighting fixtures typical in commercial applications. Push in terminals accept #14 solid wire only. Temperature rating of -20 to 60 deg C. Meets flammability requirements per UL 94, 6504, V2 rated, VO rated. UL and cUL listed, meets all UL20 requirements.
Product specification\n\n
\n
| Brand | Eaton Wiring Devices |
|---|---|
| UPC | 032664628030 |
| Model Number | 7513V-BOX |
| Application | For fluorescent lighting fixtures and a broad variety of applications |
| Feature | Redesigned paddle for easier actuation and quiet operation |
| Category | ELECTRICAL |
| Additional Category | Rocker Switches |
| Length | 7.38 |
| Width | 3.88 |
| Height | 4.4 |
| Weight | 0.18 |
