Load Centers are enclosures specifically designed to house the branch circuit breakers and wiring required to distribute power to individual circuits. They contain either a main breaker when used at the service entrance point or a main lug when used as a sub-panel to add circuits to existing service. The main breaker protects the main entire panel and can be used as a service disconnect. The branch breakers protect the wires leading to individual electrical loads such as fixtures and outlets.
Product specification\n\n
\n
| Brand | Cutler-Hammer |
|---|---|
| UPC | 782114190456 |
| Model Number | CH2L70RP |
| Application | For combination service entrance devices |
| Feature | For service entrance applications, all that is required to bond the neutral is to loosen the bonding screw and the neutral screw directly beside it, insert the bonding strap into the neutral bar and retighten both connections |
| Category | ELECTRICAL |
| Additional Category | Main Lug Load Centers |
| Length | 11.0 |
| Width | 4.5 |
| Height | 5.25 |
| Weight | 3.5 |
